Apollo Valves 61LF-105-01PR In-Line Ball Cone Check Valve
Apollo® Valves 61LF-100 61LF-105-01PR In-Line Ball Cone Check Valve, 1 in Nominal, Press Connection, Brass Body
Apollo® Valves 61LF-100 61LF-105-01PR In-Line Ball Cone Check Valve, 1 in Nominal, Press Connection, Brass Body 61LF-105-01PR- Brand Name: Apollo® Valves
- PN: 61LF-105-01PR
- UPC: 670750663703
- Min. Order Qty: 1
- Qty. Interval: 1
- Click for Availability
-
$188.00
Add To Favorites ListApollo® CVB-LF (61LF Series) Ball Cone® check valves offer reliable protection against reverse flow and exceptional resistance to chemicals and corrosion using proven ASTM grade lead-free materials. They are well-suited for a broad range of applications, including saturated steam and chemical service. They may be installed in both horizontal and vertical orientation with upward flow.
Apollo® Valves In-Line Ball Cone Check Valve, Series: 61LF-100, 1 in Nominal, Connection Type: Press, 250 psi, 0 to 250 deg F, 6 gpm Flow Rate, Full Port, Gas, Liquid Media, 5.8 in L Inlet to Outlet, Brass Body, RPTFE Seat, EPDM Seal, Lead-Free/Contains Lead: Lead-Free
| Body Material | : | Brass |
| Connection Type | : | Press |
| Flow Rate | : | 6 gpm |
| Inlet to Outlet Length | : | 5.8 in |
| Lead-Free/Contains Lead | : | Lead-Free |
| Media | : | Gas, Liquid |
| Nominal Size | : | 1 in |
| Port Type | : | Full |
| Pressure Rating | : | 250 psi |
| Seal Material | : | EPDM |
| Seat Material | : | RPTFE |
| Series | : | 61LF-100 |
| Temperature Rating | : | 0 to 250 deg F |
- Bubble-tight shut-off, ideally suited for gaseous service
- Straight through flow minimizes pressure loss
- 1/2 psi cracking pressure
Instruction/Installation Manual
